Ladle Transfer Cart

Steel ladle flat car is designed with safety in mind. It has a sturdy, reliable frame that can withstand the weight of even the heaviest materials. Its wheels are also specially designed to provide maximum stability, reducing the risk of accidents and ensuring that workers are safe at all times.

Henan Perfect company has rich production experience, advanced technology, and has its own R&D team. It specializes in the production of various types of handling equipment such as rollover and dump electric flat cars, electric flat cars, trackless electric flat cars, and track electric flat cars. Various countertops, functions, and electric flat cars can be customized according to customer needs. When customizing, customers must provide the required parameters according to the needs of technicians in order to make more practical products and reduce user costs.

Ladle transfer cart is a kind of transfer cart used to transport specific high temperature ladle. Due to high temperature and high safety requirements, the requirements of the body material, transmission system, and electrical control of the ladle transfer cart are higher than those of ordinary transfer carts. In order to prevent molten steel or steel slag from splashing, the traction motor on the transfer vehicle is designed to start and stop slowly to reduce inertia. The car body is equipped with heat insulation material to prevent high temperature radiation of the package body. In order to better ensure the transportation of molten steel, under normal circumstances, a dual drive system is adopted. Once one of the systems fails, the other is guaranteed to complete a process cycle.

Transfer Cart For Transporting Steel Ladle

Ladle transfer cart is a transfer cart used to transport special high temperature ladle. Due to high temperature and high safety requirements, the requirements of the body material, transmission system and electrical control of the ladle transfer cart are higher than those of the ordinary transfer cart.

PERFECT Ladle Handling Vehicle are extensively used for moving and transporting hot metal ladles to the ingot casting machines or within the plant itself. These are well known for their capacity to bear enormous weight easily and equipped with two driving mechanism to keeping working when one is damaged by ladle high temperature.Our transfer cars are easily maneuverable and heavily demanded by organizations engaged in conducting metallurgical operations.

Our BXC series ladle transfer cart is powered by battery. The battery is fitted in the inner of the cart. The direct-current machine gets its power from the electric control system, which make the cart to start, stop, move forward and move backward. It could run on straight line, L-form track or curved track. We can also fit hydraulic lifting system if needed. The heat insulating material is used to prevent the high temperature. In case to handle emergency situations, two motors are assemlied in the car to make sure the machine works smoothly when one motor is broken.

With the functions of steady traveling, stepless speed regulation, the Molten Steel Ladle Transfer Car is commonly applied to transfer steel ladle, aluminum ladle, lead ladle, steel slag etc. Generally the outer surface temperature of the ladle is 200-300 degree , due to the high temperature, the Molten Steel Ladle Transfer Car should be designed with heat exposure proof device, especially to the battery, motor, reducer and electric appliance.
It can avoid the cart from damaging and shortening using time. During the cart working, it must be steady travel, steady start and slowly stop. In order to avoid the cart broken during working, there equipped two sets driving system, if the main driving system is broken, the spare driving system can be start at the same time.
