Rail Transfer Trolley

The rail transfer car running on turntable is also called electric track car, track rotating platform, track car. rail transfer car running on turntable is mostly used with the track flatbed to help the track flatbed to carry the steering. The track flatbed goes along the track to the rail transfer car running on turntable, the rail transfer car running on turntable rotates to dock with another track, and the track flatbed runs along the other track to complete the work

Henan Perfect Handling Equipment Co., Ltd.  is specializing in the design and manufacture of heavy material transport system to solve every material handling requirement. Our product includes Industrial Trailers, Transfer Cars, Electric Railway Transfer Trolley, Battery Operated Transport Trolley, Coil and pipes Carrier Equipment, Ladle Handling Equipment, Hydraulic Lift Table, Turntables and many other specialty items.Our line of Industrial Transfer Carts are designed and manufactured to accommodate the needs of a wide range of industries including Steel, Aluminum, Automotive, Heavy Manufacturing and others. These material handling equipment are designed to operate on floor mounted rails and are used to transport heavy materials across crane bays or in areas not serviced by an overhead crane.

35t Remote Control Material Handling Rail Transfer Cart Rated Load:1-300(t) Table Size: Customized Running Speed:0-20(m/min) On Rail: yes/no Warranty:1 year Feature Mold field:Heavy industry、Workshop and so on Application Table:Flexibility、Safety、High using frequency and so on

Railway Transfer Platform Cart is an electric material handling transfer vehicle installed on the track, designed for workshop material and equipment transportation. The driving system of this series of railway platform cars is an electric motor and a reducer. Customers can use this cart from us, and its specifications range from 1 ton to 500 ton.

Turn table and Battery operated trolly The 3 ton trackless transfer vehicle is used in the workshop to transport materials, from the workshop to the finished product warehouse, instead of forklifts, which is convenient, safe and efficient

Battery Powered Rail Transfer Heavy Load Cart
Rail flat car and turntable transfer system, used for workshop transfer, battery rail car, including two electric turntables, used in conjunction.
Battery Powered Rail Transfer Heavy Load Cart
Battery powered, there are audible and visual warning lights when driving, when you brake, the power will be automatically cut off when the battery is fully charged. Reflective warning oblique bar, wired handle and wireless remote control two operation modes.

Electric motorized 10ton Rail Transport Platform.It can be used for the construction of highway first-class bridges, the transfer of materials by rail cars, the transportation of prefabricated beams and parts, etc.
Electric motorized 10ton Rail Transport Platform
Power Supply:Battery Powered
Material:Q235
Load Capacity:1-300T
Running Speed:0-20m/min
Certification: CE ISO SGS
Application:Factory ,warehouse And Working Line
Warranty:1 Year
Color:Customized
OEM:Accepted

hudrauli protable lifting platform electric rail transfer cart
The dual power supply mode of battery and track low-voltage power supply, with a lifting platform, can be used for maintenance of shipyards and manufacturing equipment plants, and can be moved in all directions.

Henan Perfect Handling Equipment Co., Ltd.  is specializing in the design and manufacture of heavy material transport system to solve every material handling requirement. Our product includes Industrial Trailers, Transfer Cars, Electric Railway Transfer Trolley, Battery Operated Transport Trolley, Coil and pipes Carrier Equipment, Ladle Handling Equipment, Hydraulic Lift Table, Turntables and many other specialty items.Our line of Industrial Transfer Carts are designed and manufactured to accommodate the needs of a wide range of industries including Steel, Aluminum, Automotive, Heavy Manufacturing and others. These material handling equipment are designed to operate on floor mounted rails and are used to transport heavy materials across crane bays or in areas not serviced by an overhead crane.

A trackless heavy-duty transfer vehicle driven by a motor driven by a motor and a gear reducer. Rubber wheels can reduce damage to the ground, sometimes directly on the factory floor, without a limited running distance. 360° on-site steering to a narrower space operation, no angle protection, sound and light alarm, limit damping, encountering people stop and other devices to protect the safety of workers. The installation of PLC has become a fully automatic, unattended function that makes it more intelligent and has become a pioneer in the industry 4.0 era. A battery supplies power to a DC motor through an electrical control system. We can make the trackless transfer cart start, stop, forward, retreat, turn, adjust speed and so on.

The material of the axle for the Rail Joint Gap Measuring Cart is 45 # steel with good mechanical properties.
The coupler of Rail Joint Gap Measuring Cart is drum gear coupling with 45 # or 40Cr forging material. The gear face is quenched in salt bath furnace. The coupler features high efficient transmission, easy installment, and maintenance. The straightness between two axles is adjustable to ensure the cart running steadily.
The electrical equipment of Rail Joint Gap Measuring Cart adopts DC overload protective device and smoothly speeding up starting device all controlled by modules. Compared with past contacting conduction, this makes the cart start strongly and steadily, and largely reduces sparks generated by a load.
PERFECT’s solutions can be applied to light duty, medium duty, and heavy-duty trucks to address a full range of inspection and operational requirements.

The rail inspection cart is always used for track maintenance and inspections.
The rail inspection cart includes safety seats, transmission system, control cabinet, a Lithium battery set, and intelligent charger with a USB socket.
The rail inspection cart also named rail repair cart or full automatically rapid detection cart, likes a magical small cart running on a rail.
The rail inspection cart is a new kind of modern rail detection carts with independent research and development designed by Henan Perfect Handling Equipment Co., Ltd.
The rail inspection cart is high test efficiency, powerful automated real-time data processing functions, multi-environment adaptability, and self-propelled cruise detection unique function.
The rail inspection cart fills the gaps in this field at home and abroad.
The rail inspection cart has brought a new change for the high-speed railway construction and operation and maintenance.

Perfect Rail Joint Gap Inspection is a self-propelled rail-bound vehicle that measures both track geometry and catenary. The joint gap inspection collects and records extensive information on track conditions. Monitoring track conditions over time will give railroads a better understanding of their maintenance needs and schedule. The machine is staffed by a three-man crew.

A steel customer in Wuhu. This company is mainly engaged in the steel coil and sheet processing industry. In 2020, we ordered a 50-ton low-voltage rail-powered transfer cart from our company. The transfer cart is mainly used for the handling of steel coils.

PERFECT is specialized in designing and manufacturing of heavy duty material transport equipment:
Transfer Cart: Rail transfer cart, Trackless transfer car, Battery operated transport trolley, Coils cart, Ladle transfer cart, Hydraulic scissors lift table cart etc.
Industrial Trailer: Flatbed trailer, Factory trailer, Utility trailer, Workshop transfer trailer, Airport baggage cargo trailer, Car transport trailer, Motorized transfer trailer etc.
Cargo Transportation:Die cart, Coils transport cart, pipes transfer carriage, steel beam transporter, aluminum plate transport vehicle, transformer carrier bogie
Speical Handling Equipment: Ladle transfer trolley, Ferry Transfer wagon, Cross-rail transport equipmet, Motorized turntable, Vacuum furnace transfer cart, Automatic vehicle etc.

PERFECT is specialized in designing and manufacturing of heavy duty material transport equipment:
Transfer Cart: Rail transfer cart, Trackless transfer car, Battery operated transport trolley, Coils cart, Ladle transfer cart, Hydraulic scissors lift table cart etc.
Industrial Trailer: Flatbed trailer, Factory trailer, Utility trailer, Workshop transfer trailer, Airport baggage cargo trailer, Car transport trailer, Motorized transfer trailer etc.
Cargo Transportation:Die cart, Coils transport cart, pipes transfer carriage, steel beam transporter, aluminum plate transport vehicle, transformer carrier bogie
Speical Handling Equipment: Ladle transfer trolley, Ferry Transfer wagon, Cross-rail transport equipmet, Motorized turntable, Vacuum furnace transfer cart, Automatic vehicle etc.

The Flat Ferry Carriage is designed to transport heavy cargo and equipment from one place to another in industry factory, which aims to increase the transferring efficiency and reduce the usage of forklifts.Though the forklifts are common transporter for material handling, but it needs professional driver to operate it and it has large potential dangerous for workers. So not every warehouse or producer want need this item. Considering the safety concerns and the potential damage of both products and workers, more and more plant managers are looking for one solution for more efficient and safe. That is exactly the selling concept of battery transport cart, which is one popular heavy duty material handling equipment for factory transportation.

PERFECT’s transfer carts, also known as cross flat cart, transfer trolley,electric flat cart, have advantages as simple structure, easy operation and maintenance,large load capacity and so on,with which these transfer carts are widely used in machine manufacturing and metallurgical factory matching up with lift cranes to transport heavy objects warehouse across.The rail transfer carts are suitable for various industries, steel mill and factory, paper roll plant,painting room,shipbuilding,new factory building project,machine processing line,heavy industry, airport and so on to transfer or handling material and equipment from one place to another, from warehouse to workshop.

Henan Perfect Handling Equipment Co., Ltd offers a wide range of automated workshop bogie specifically designed for the unique needs of stamping, molding, heavy die, bulk cargos, foundry and many other heavy duty things transporting or mold from die storage to the press line.
The body of the automated workshop bogie is made of thick steel plate and with super anti-distortion performance. All the bogies are equipped with warning alarm and security detection devices, and the alarm would ring and the car would stop immediately once there was any obstacle or pedestrian in the running path of the automated workshop bogie.

PERFECT’s transfer carts, also known as cross flat cart, transfer trolley,electric flat cart, have advantages as simple structure, easy operation and maintenance,large load capacity and so on,with which these transfer carts are widely used in machine manufacturing and metallurgical factory matching up with lift cranes to transport heavy objects warehouse across.The rail transfer carts are suitable for various industries, steel mill and factory, paper roll plant,painting room,shipbuilding,new factory building project,machine processing line,heavy industry, airport and so on to transfer or handling material and equipment from one place to another, from warehouse to workshop.

Our coil transfer cart are used to transport steel coils and pipes for the metal industry.
This coil transfer Cars are designed to be an extremely cost-effective, safe and flexible load moving alternative. Our coil transfer carts are specially designed for coil, pipe and other round material transportation.
There are mounted V-shape and Roller on coil transfer cart to protect the coil stable, roller distance can be adjusted as per coil diameter, V-shape supporting and roller can also be removable from the cart for other cargo transport.
The coil transfer cart was developed to dramatically reduce the material handling requirements of cranes and fork trucks while providing quick, safe and smooth movement of materials and products through manufacturing facilities.
when the goods are loaded, we can make sure the cart moves safely and the goods are in a very safe condition.

PERFECT Rail Flat Trolley is used to transport heavy machinery and material for industry and construction site etc. This Rail Flat Trolley is designed to be an extremely cost effective, safe and flexible load moving alternative.
They are manual guide vehicles equipped with specialized drive systems which make it possible to easily, precisely and safely move up to 200 tons. The Rail Flat Trolley is sometimes called a heavy transporter, headless transporter or self-propelled modular transporter.

With the functions of steady traveling, stepless speed regulation, the boiler transfer trolley is commonly applied to transfer steel ladle, aluminum ladle, lead ladle, steel slag etc. Generally the outer surface temperature of the ladle is 200-300 degree , due to the high temperature, the boiler transfer trolley should be designed with heat exposure proof device, especially to the battery, motor, reducer and electric appliance. It can avoid the cart from damaging and shortening using time. During the cart working, it must be steady travel, steady start and slowly stop. In order to avoid the cart broken during working, there equipped two sets driving system, if the main driving system is broken, the spare driving system can be start at the same time.

The rail mounted transfer cart is a flatbed truck that runs on a track and driven by a power motor, which greatly improves speed and efficiency. It is also called an electric flat car, rail transport vehicle, electric flatbed car and so on.

Rail transfer trolleys are an electric transport trolley on rail tracks that address product transport between factory spans. Also known as cross-bay rail trolley, cross-transfer table, electric flat car. The utility model has the advantages of simple structure, convenient use, easy maintenance, large carrying capacity, and less pollution. Widely used in machine building, metallurgical factories, as a workshop to cooperate with cranes to transport heavy loads. the powered by the battery, cable drum, or rail powered, etc.

The rail mounted transfer cart is a flatbed truck that runs on a track and driven by a power motor, which greatly improves speed and efficiency. It is also called an electric flat car, rail transport vehicle, electric flatbed car and so on. As for the rail mounted transfer cart structure, it is generally composed of an electrical control system, traveling wheel system, power supply system, drive system, and frame. These are the basic structural components of the track flat car

The Turning Electric Rail Transfer Cart is our patent product.It can move on S shape,Arc shape and combined rail and arc rail.Small turning radius,stable and flexible turn.Our most advantage is that we optimize the complicated steering mechanism and control mechanism.It is our characterized product.It reduces the production cost and maintenance simply.
The Turning Electric Rail Transfer Cart needs to go to the site to actually measure the track radius.

BXC Series Die Transfer Trolley is powered by storage battery. It is a kind of transfer cart running on the cement within or between workshops in the factory.

Power supply AC 380v is obtained through Cable Reel Transfer Cart. The motor is controlled by AC control system to start, stop, advance, retreat and speed regulation.

Heavy duty rail transfer cart is a type of car that runs on a track and is generally used to carry and transport large items. There are many ways to carry supplies, such as cranes and forklifts. Then when do we choose Heavy-duty rail transfer cart trolley?

The steerable transfer trolley is a wheeled handling device that can be steered by manual steering. The power supply mode is battery power supply, and the drive wheel and the load wheel can be selected from high-strength urethane rubber solid tires or pneumatic tires. The rail transport trolley is a wheeled handling device that can be arbitrarily controlled by manual steering.

The cross rail transfer cart is an electric rail plant in-transit vehicle that resolves product transport between factory spans. Also known as trolleys, electric flat cars. The utility model has the advantages of simple structure, convenient use, easy maintenance, large carrying capacity and less pollution. It is widely used in machine building and metallurgical factories, and it is used as a crane to transport heavy loads across the workshop.

Battery operated material transfer trolley cart, as a cross-over vehicle in the factory area and workshop, can not only walk straight or turn but also greatly enhances the convenience of transportation across regions. The technical difficulty of the material transfer trolley is the wheel pressure problem of the hydraulic steering structure and the polyurethane rubberized wheel.

The rail guided ladle car, also known as the steel water truck. It is also an electric flat car specially developed by a steel mill to transport high-temperature ladle.
The rail guided ladle car is a flat car used to transport a specific high-temperature ladle. Due to the high temperature and safety, the requirements of the rail guided ladle car body material, the transmission system, and the electrical control are quite different from those of the ordinary rail car. In order to prevent splashing of molten steel or steel slag, the motor starts and stops at a slow speed to reduce inertia. In order to prevent the high-temperature radiation of the ladle, the inside of the rail guided ladle car body is provided with heat-insulating material. In order to prevent the steel temperature from affecting the damage to the motor, Adopt double motor, one is damaged and the other can continue to work normally. The heavy duty rail-guided ladle car, also known as the steel water truck. It is also an electric flat car specially developed by a steel mill to transport high-temperature ladle. Due to the high temperature of molten steel and steel slag, the use of ordinary transfer electric vehicles will cause a series of hazards. In order to avoid the accident of steel and steel slag splashing, causing burns to employees. Our company can customize the product to satisfy customer’s needs on the basis of guaranteeing the customer’s needs.

PERFECT’s transfer carts, also known as cross flat cart, transfer trolley,electric flat cart, have advantages as simple structure, easy operation and maintenance,large load capacity and so on,with which these transfer carts are widely used in machine manufacturing and metallurgical factory matching up with lift cranes to transport heavy objects warehouse across.The rail transfer carts are suitable for various industries, steel mill and factory, paper roll plant,painting room,shipbuilding,new factory building project,machine processing line,heavy industry, airport and so on to transfer or handling material and equipment from one place to another, from warehouse to workshop.


Solid design, thickened of welded steel plate, and anti shape-shifting bearings installed in plant for carrying aluminum coils and steel pipes, one place to another place, with our rich industrial experience; We have been able to catch up with a wide range of coil transfer truck. They occupy sufficient ground clearance. Customizable features like rotating light, table size, warning alarm, storage battery, low voltage rail, cable reliving drum (Spring Drum/Magnetic Coupling Drum) can be supplied as per the customer’s needs and applications.

Assembly Line: Due to advantage of without cable, it is mainly applied in assembly line, can realize the straight rail, S shape rail, U shape rail, C shape rail, Arc-shaped rail, 90 degree turn rail, crossing rail etc.
Metallurgy industry: With the functions of steady traveling, stepless speed regulation, the cart is commonly applied to transfer steel ladle, aluminum ladle, lead ladle, steel slag etc.
Warehouse transport: The cart is applied to transfer heavy material from one warehouse to another or from warehouse to factory (eg.transfer paper coils in paper mill, transfer large package ), it can travel in all kinds of rails. With automatically operate, it can greatly improve the working efficiency.
Ship industry: Due to the large load capacity, the cart is applied in ship industry to transfer workpieces, maintenance tools(propeller, motor etc.).
The cart is also applied in dock or harbor to transfer cargoes and containers. If needed, the hydraulic lifting device , weighing device and automatic device can be added.
Workshop: The cart is mainly applied in machining workshop, manufacturing workshop, mold workshop to transfer machining parts, finished products, castings etc.
Painting room: The cart should be producing fire during working. In order to avoid explosion, the motor, reducer, electric appliance, pendant and alarm should protected and explosion-proof.

Our BDG series rail powered transfer car get its power from railway. The 380V alternating-current is transformed into safe current 36V. The current collectors mounted on truck get the 36V current from the condustive rails and transmit it into electronic box and thus to make the car start, stop, move forward and move backward. Combined with PLC system, full automatic operation is available. It’s widely used, service long time, safe and flexible.

PERFECT’s battery transfer trolleys are movable platforms used for the horizontal movement of materials, assemblies and other items. It is powered by storage battery, which is installed on the transfer carts. The transfer carts are manual guide vehicles equipped with specialized drive systems which make it possible to easily, precisely and safely move up to 200 tons. Usually the vehicles are used to accommodate the needs of a wide range of industries including Steel, Aluminum, Automotive, Heavy Manufacturing and others.These cargo loading trolleys are designed to operate on floor or rails and are used to transport heavy materials across crane bays or in areas not serviced by an overhead crane.

PERFECT motorized transfer carts are used to transport steel coils and pipes for metal industry. This coil transfer trolleys are designed to be an extremely cost effective, safe and flexible load moving alternative.
The electric transport bogies are manual guide vehicles equipped with specialized drive systems which make it possible to easily, precisely and safely move up to 200 tons. The coil heavy load transfer cart is sometimes called a heavy transporter, headless transporter or self-propelled modular transporter.

The on-rail special transfer cart along a fixed path loads up to 300 tons. Custom deck frames can be designed for specific assemblies to carry an entire shift of production and even serve as a stable movable machine base. These on-rail special transfer carts are mounted on steel rail for shuttling along a fixed path. They can be DC battery powered or AC powered. Typically used for moving materials such as steel tubes, tanks of liquids, steel coils, steel beams, machine parts from one location to another. Standard sizes from 4 x 4 to 6 x 8. Larger cart capacities and sizes are available for specific applications.

PERFECT is specialized in designing and manufacturing of heavy duty material transport equipment:
Transfer Cart: Rail transfer cart, Trackless transfer car, Battery operated transport trolley, Coils cart, Ladle transfer cart, Hydraulic scissors lift table cart etc.
Industrial Trailer: Flatbed trailer, Factory trailer, Utility trailer, Workshop transfer trailer, Airport baggage cargo trailer, Car transport trailer, Motorized transfer trailer etc.
Cargo Transportation:Die cart, Coils transport cart, pipes transfer carriage, steel beam transporter, aluminum plate transport vehicle,  transformer carrier bogie
Speical Handling Equipment: Ladle transfer trolley, Ferry Transfer wagon, Cross-rail transport equipmet, Motorized turntable,  Vacuum furnace transfer cart, Automatic vehicle etc.

Perfect Material Handling offers a wide range of Die Handling Products specifically designed for the unique needs of both stamping and molding and transporting heavy die or mold from die storage to the press line. These die transfer cart is widely used in the processing line of
punching, pouring, cold heading, extrusion, powder metallurgy parts pressing, pressure casting, and engineering plastics, rubber, ceramics and other products of the compression molding or injection molding. Our die transport products are operated on rails or travel on cement floor, and include die transfer cart, die transport trolley, die rail cart, trackless carrier, battery operated carriage, electric flat vehicle, industrial trailer, motorized railway bogie, steering platform table and so on.

PERFECT is specialized in designing and manufacturing of heavy duty material transport equipment. Our main products include material transfer carts, coils and pipes transport trolleys, industrial trailers, factory transport solution, electric warehouse carriages, ladle carts, motorized battery operated transfer vehicle and so on. The coil transfer carts are used to transport steel coils and pipes, die, machine parts, paper products for manufacturing industry; The factory transport solution is mainly to offer heavy duty horizontal transportation for manufacturing;while the motorized battery operated transport vehicle specially apply to transport heavy loads from one warehouse to another. With the steel box girder structure and safety devices make the electric transfer vehicle with easily, precisely and safely move up to 200 tons.

Turntables On Cross Rails is a kind of equipment to realize the in-situ turning and reversal of the track flat car. It is installed at the position where two tracks cross. One or more tracks are laid on the platform. The upper surface of the track is level with the upper surface of the track on the ground. The track gauge is the same as that of the ground. The flat car runs completely until it stops on the turntable. The turntable starts to rotate to the required angle to complete the docking with the track on the ground. The flat car starts again to run along the docked track to the required position. Its special function is a common equipment in rail transportation system. The loading weight of the trolley is the load capacity of the supporting turntable. The rotation angle of the turntable can be set according to the different needs of customers. It can stop at any angle of 360 degrees, and it can also realize the well-shaped cross operation.

The rail transfer wagon along a fixed path loads up to 300 tons. Custom deck frames can be designed for specific assemblies to carry an entire shift of production and even serve as a stable movable machine base. These rail transfer equipment are mounted on steel rail for shuttling along a fixed path. They can be DC battery powered or AC powered. Typically used for moving materials such as steel tubes, tanks of liquids, steel coils, steel beams, machine parts from one location to another. Standard sizes from 4 x 4 to 6 x 8. Larger cart capacities and sizes are available for specific applications.

The series’ rail ferry transfer car is battery powered. The battery is installed in the rail cart. The batteries supplied the electricity to the DC motor through the electrical control system. In this ways, we can make the electric ferry transfer cart to start, stop, go forward, backward, adjust the speed and so on.
For material transport: boiler, coil items, pump, transformer, shaft, drum, steel ladle, steel structure, steel pipe, mold, beam, container, heavy equipment, heavy machinery, Aluminum product, compressor, polycrystalline silicon, motor, coil, scrap, pallet…
Of course, the power supply is chosen as per your working environment, the proper solution will be recommended to you after knowing your plant. hope rich experience (more than 15 years) can help you well

The Factory Materials Handling Electric Rail Ferry Transfer Cart consists of two parts.
The upper car usually powered by battery or internal combustion engine, used to transport goods, and the upper car can be equipped with a V-shaped bracket, a lifting platform etc.
The under the car is can be powered by a battery, cable drum, rail power, designed to run underground, with rails on the deck for connecting to other rails in the workshop, so the upper deck can travel on multiple different parallel tracks.
The Factory Materials Handling Electric Rail Ferry Transfer Car enables fast and precision transitions between parallel tracks and one transfer vehicle can accommodate parallel transitions of multiple vehicles.
The two rail ferry car have independent control systems, both wired and wireless remote control can also be installed with PLC.
It is more convenient and economical than the turntable platform.

Working Principle of the ferry transfer trolley
During the work, when the mother car moves to the brick machine track ( the mother car is in the home position), the child car pulls the fully loaded steaming car to the shuttle bus, and finally, the mother car of the shuttle car moves when the reservation is reached.
The autoclave track will automatically connect to the rails, and the sub-par will push the steaming car to the steaming car track in the autoclave, then the railing device will be put away, and the mother car will return to the original position, waiting for the next ferry.

The BJT series reel-powered electric flat car has a cable reel on the electric flat car, and the cable reel is hysteresis coupled to ensure that the cable is evenly stressed and not easily pulled. The cable drum 380V power supply provides power to the motor for lifting metallurgy on the flat car, and the motor drives the flat car to run. When the electric flat car is running, the cable reel automatically rolls up or releases the cable, which is affected by the length of the reel. Generally, the maximum running distance is less than 200m. The flat car is suitable for lifting metallurgy in harsh working conditions, the flat car structure is simple and reliable, the price is economical, and the track construction is convenient.

The BJT series is a cable-powered rail transfer cart. The AC 380 cable is connected to the flat cable reeling cable to realize the flat car power supply. The reeling device is placed under the track flat car and directly controls the power supply through the AC control system. Start, stop, advance, retreat, etc. of the motor.

Cable powered rail cart is a roller handle car powered by cable reels which are installed at the bottom of the cable roller handle car. The transfer car gets power AC 380v through the device of the cable reel, and the motor is controlled by the power through AC control system that makes the flat car to start, stop, go forward, backward, adjust the speed and so on. The cable roller handles the car, we adopt the magnetic coupling cable reel, it can make sure that there is no force on the cable and the cable can be wound and released evenly. if it is used in short distance transportation, it is a better choice without limited time. It is designed for transporting cargoes or equipment from one bay to another in the factory, from indoor to outdoor. It was widely applied in the industrial transportation field.

The hand-powered rail cart is used to transfer heavy material or equipment in many industries. such as the factory, warehouse, steel plant, aluminum factory, plastic pipes factory, metallurgy, shipyard, coal, mining and processing industries, and so on.

The non-motor Transfer Cart towed by pulling device run on rails, which also is our customized products as per our customer’s requirement with U frame, it makes the transport more stable. What’s more, all design is for your convenience, it can be divided into two kinds, the fixed and the dismountable, you can transfer other material when you don’t use the frame.

We have a wide range of Material Transfer Flat Carriages to suit the job and application. This Motorized Transfer Flat Carriages is used in Painting shops, quarries, Warehouses and multi-bay workshops for transferring loads.Power feeding is done through storage battery, cable reeling drum, trailing cable or low voltage rail.
The Carriages are non-standard and designed considering pay load. Various parameters for considering the pay load include the Dimension of the load, Speed, Length, Width & Height. The Structure is made out of Q235-B structural steel and wheels are made from alloy steel and 45-50mmt polyurethane rubber wheel to suit the load and protect the floor surface.
The top platform can be a chequered plate – Plain or with a turning table in paint shop or with perforated sheets, depending upon the application.

These series Die cart manual is driven by manual or other power machines.
These series die cart manual is able to run between two perpendicular tracks and the car is also could run on L-form track or S-form track or curved track. Also, die cart manual on rail is specially designed to cooperate with a crane, which has been applied in many factories to transfer conductor or materials from one workshop to another. The die cart manual has a feature of low height, heavy duty, safe security, and other advantages.

The manual transfer carts have no power and are meant to be pulled or towed by another powered transfer cart or a forklift of adequate capacity. They are a cost-effective choice of acquiring another powered transfer cart. For on-rail types, a winch can be applied to move trailers. Pull type mobile manual transfer cart are versatile and can be easily customized to suit the applications.

The heavy load battery powered transfer vehicle is made up of the battery as the power source of the series of flat cars. It supplies power to the flat car. The DC current flows into the electric box, and the electric box is supplied to the operating system and the motor. The control unit or the remote control controls the motor. Reverse, stop, etc., and then control the forward, backward, start, and stop of the flat car.

The Motorized Rail Transport Carriage shuttles along a fixed path and they are available in two propulsion types – AC electric or DC Storage Battery.  Larger railway Transfer Carriage capacities and sizes are available for specific applications. Our Motorized Rail Transport Carriage loads up to 300 tons and the custom deck frames can be designed for specific assemblies to carry an entire shift of production and even serve as a stable movable machine base.
The key features are that they are easy to operate for material handling and have low noise level with highest safety.

he Coil Transfer Cart is mainly adopted to transport metal coils, pipes, beam, or other round materials. We can design the cart’s capacity, table size, power supply style due to your working condition. To protect the round cargo falling down, V shape supports are available to be equipped on the Plant Transfer Cart according to customer’s application requirements. The V shape support of Plant Transfer Cart could be removed when not using, so that it can be used for other materials. The Coil Transfer Cart can realize cargo transfer among crossing rails with two layers body, which also could be used separately.

The battery-powered rail transfer vehicle is called battery platform transfer car, and the battery is installed on the flat vehicle to directly supply power to the traction DC motor. The battery supplies power to the DC motor through an electrical control system. In this way, we can make the transfer car start, stop, advance, retreat to the ward, adjust the speed and so on. Due to its battery power, it gets rid of the cable limitations and does not have strict track requirements. A variety of battery platform transfer car can be operated remotely, making them more convenient and safe. More importantly, due to this power, as long as it is fully charged, it can operate without a limited distance.

Battery powered platform cart powered by a battery. The battery is installed inside the flat car. The power supply is supplied to the DC traction motor through the electric control system. The flat car starts, stops, advances, retreats and adjusts the speed, etc.

Battery powered transfer carts for industrial material handling, powered by a lead-acid battery, can only be equipped with a charger, can be recharged and automatically powered off after charging, environmentally friendly and durable.
This series of battery-powered transfer carts for industrial uses a DC motor for speed regulation. Because there is no cable, there is no limit to the running distance and route. You can not only take a straight line, but also take the “C” or “S” type route, but there is a requirement for the turning radius. If you support the electric turntable, you can not only run the cross. The route can also be docked at an angle of 360°.
Battery powered transfer carts can be used indoors and outdoors, suitable for ambient temperature -30 °C – 70 °C. The battery capacity is limited, and there is a limit to the working time. The battery capacity can be increased according to the work intensity to extend the working time.

The battery-powered rail transfer cart is made up of the battery as the power source of the series of flat cars. It supplies power to the flat car. The DC current flows into the electric box, and the electric box is supplied to the operating system and the motor.

The rail powered trolley is an electric flat trailer produced by the Henan Perfect Handling Equipment Co., Ltd. The series car can run on S shape or Arc shape rails. It is safe and flexible, but the rail needs to be insulated in erection. When the running distance is longer than 70m, the transformer needs to be increased to raise the voltage. The series trolley is suitable for heavy-duty load, high using frequency and meets full automation demand.

The working principle of BDG series electric flat car is as follows: the AC 380V power supply is stepped down to the AC 36V two-phase through the transformer and connected to the two rails respectively. The wheels on the track flat car introduce the AC 36V power supply on the track into the vehicle electrical equipment. The box, through the rectifier module, rectifies the AC 36V to DC 36V and then controls the DC motor through the DC control system to make the flat start, stop, advance, retreat, speed regulation and so on.

Our line of Material Transfer Equipment is designed to accommodate the needs of a wide range of industries such as steel, aluminum, automotive, stamping, heavy manufacturing and several others. These units are designed to operate on floor mounted rails and are used to transport heavy materials across crane bays or in areas not serviced by an overhead crane.

Our coil transfer cart are used to transport steel coils and pipes for the metal industry.
This coil transfer Cars are designed to be an extremely cost-effective, safe and flexible load moving alternative. Our coil transfer carts are specially designed for coil, pipe and other round material transportation.
There are mounted V-shape and Roller on coil transfer cart to protect the coil stable, roller distance can be adjusted as per coil diameter, V-shape supporting and roller can also be removable from the cart for other cargo transport.
The coil transfer cart was developed to dramatically reduce the material handling requirements of cranes and fork trucks while providing quick, safe and smooth movement of materials and products through manufacturing facilities.
when the goods are loaded, we can make sure the cart moves safely and the goods are in a very safe condition.

The BDG series electric flat cart is a 36V low-voltage rail-powered electric flat transfer car. Its working principle is based on the rail sliding line. The ground step-down transformer control cabinet steps down the single-phase AC 380V to a single 36V safe voltage. After passing the track, it is boosted to a single-phase AC 380V by the onboard step-up transformer. Power is supplied to the flat car with a DC traction motor.

The battery powered rail transfer car is made of high quality carbon steel that guarantees the cart’s big bearing ability, reliability, and safety. And it also has a very big weight capacity of 1-300 ton. Positioning ficture , lifting platform and other assistive device are also optional to meet dofferent demands on various occasions.

The 5t battery rail transfer cart is currently the most used electric flat car. The 5t battery rail transfer cart is very convenient to use, it can be operated after charging, and it can be charged once a week under normal working conditions, with high safety and maneuver flexibility.

A company in Wuxi, Jiangsu, ordered a battery powered on rail transfer trolley in our company. The company is doing wood processing. The flat car is ordered to carry the wooden board. We have fixed brackets on the flat car. There are rollers on the bracket. The roller can be rotated automatically, the plank can be transferred to the middle of the flat car along the roller, and then the board is transported to the processing room. The customer said that this flat car not only saves manpower handling but also saves the car transportation. It is more than one car and said that it will add two more.

The battery powered rail transfer trolley is a transfer vehicle that uses a battery as a power source, a motor reducer as a drive system, and a solid rubberized wheel to walk directly on the ground. Its operation is not restricted, the imported wheels prevent ground damage, and the 360° in-situ turn adapts to a small size. The space operation, 360-degree multi-directional protection, automatic stop and other functions ensure the safety during the operation. The touch screen, joystick operation and other designs make the operation more user-friendly. Fully automated, unmanned features make it smarter

The battery powered on rail transfer trolley is a kind of handling equipment with the battery as the power source, which can handling heavy load materials. It can be free from remote control when it is free from the constraints of cables. It is more convenient and safe to use and is suitable for long-distance rail transit systems.

The battery powered rail transfer trolley is a transfer vehicle that uses a battery as a power source, a motor reducer as a drive system, and a solid rubberized wheel to walk directly on the ground. Its operation is not restricted, the imported wheels prevent ground damage, and the 360° in-situ turn adapts to a small size. The space operation, 360-degree multi-directional protection, automatic stop and other functions ensure the safety during the operation. The touch screen, joystick operation and other designs make the operation more user-friendly. Fully automated, unmanned features make it smarter

The heavy load battery powered transfer vehicle is made up of the battery as the power source of the series of flat cars. It supplies power to the flat car. The DC current flows into the electric box, and the electric box is supplied to the operating system and the motor. The control unit or the remote control controls the motor. Reverse, stop, etc., and then control the forward, backward, start, and stop of the flat car.

Our line of Material Transfer Equipment is designed to accommodate the needs of a wide range of industries such as steel, aluminum, automotive, stamping, heavy manufacturing and several others. These units are designed to operate on floor mounted rails and are used to transport heavy materials across crane bays or in areas not serviced by an overhead crane.

High Efficiency Ferry Cart for Production Line Its working principle: This high-efficiency ferry cart is generated by battery power supply, the battery is installed inside the electric ferry cart, the battery supplies power to the DC traction motor, and commands such as start, stop, forward, reverse, speed regulation is issued through the remote controller, and the flat cart electric control system issues the command DC. The motor drags the electric ferry cart to run.

The rail traverser transfer cart consists of the upper body and the lower body. The lower body is used for ferries or for transporting goods. Generally designed in the underground, the upper cart level is parallel with the underground level. The transfer trolley can realize material transfer among crossing rails.

The rail material handling flat traverser is mainly applied in assembly line(ring production line, loop production line),metallurgy industry(steel lade),warehouse transport, ship industry(maintenance assemble, container transport),work piece transport in workshop, lathe transport, steel factory(steel billet, steel plate, steel coil, steel pipe, section steel structure),construction(bridge, simple building, concrete column,)petroleum industry(oil pump, sucker rod and parts),energy(polycrystalline silicon, generator, windmill), chemical industry(electrolytic cell, retort etc),railway(rail maintenance, rail welding, train tractor).

Our BXC series rail transfer wagon is powered by batterry. The battery is fitted in the inner of the cart. The direct-current machine gets its power from the electric control system, which makes the cart to start, stop, move forward and move backward. It could run on straight line, L-form tracks or curved tracks. We can also fit hydraulic lifting system if needed.

Battery steerable transfer cart is powered by the lead-acid storage battery. transfer cart CMOD(control module) is the control core, meanwhile the operation ways are hand held push button and remote control, the steering wheel sets coordinate with die wheelsets to carry the loads on the customized platform. This series steerable transfer cart’ original power source is DC motor power, through reducer enlarge the torque and provide power to die wheelsets. The safety device is LED audible and visual alarm as a warning symbol, and the external automatic charger is equipped for battery recharge. In conjunction with the above functions, jointly consist the battery steerable transfer cart working capacity.

The large die mold transfer carriage is mainly used for mold transfer shifting in industrial production workshops and for mold change. The size and rated lifting capacity of the large die mold transfer carriage can be designed and manufactured according to the needs of users. The control mode wireless remote control device is optional and can also be automatically controlled. The speed of the large die mold transfer carriage can be selected by the inverter to control the speed. It can be equipped with an alarm device and an infrared sensor according to the actual working conditions to realize automatic parking of 2 meters for people to ensure the safety of the workshop.

rail transfer cart In order to meet the production needs of different products in the large-tonnage track flat-panel workshop, different molds need to be replaced frequently, but the weight of the rail transfer cart mold is large, the volume is large, and the transportation methods such as forklift driving cannot meet the production and transportation requirements, so it can be adopted. The large die mold rail transfer cart transports the mold from the warehouse to the underside of the required molding machine on the track to realize the need for rapid mold change.

The electric die cart is powered by a battery. The battery supplies power to the DC traction motor, and the DC motor drives the flat car to run. Compared with AC motors, DC motors are not easy to burn, have large starting torque and strong overload capability. The running distance is not limited. The electric die cart has greater safety performance and flexibility, and the running distance is not limited. There is no insulation requirement, so the construction is convenient and the cost is low, so as to better guarantee the normal operation and work of the electric motor, and then control the AC metallurgical motor through the AC control system to make the flat car start, stop, advance and retreat. The running distance of the electric die cart is not limited, but the battery needs regular maintenance, and the battery life is generally about 2.5 years, and the use time is limited.

The concrete mould transfer carriage on rail is a kind of railway electric transport car in the factory. It has the characteristics of simple structure, convenient use, large carrying capacity, no fear of dirt, no fear of smashing, easy maintenance and long service life. Because of its convenience, economy, practicality, easy cleaning and many other advantages, it has become the inside of the factory building and factory. The preferred conveyance for moving heavy objects between rooms and factories is regular and fixed.

The aluminum coil turning transfer cart are mainly used in assembly line, metallurgical industry, warehousing transportation, shipbuilding industry (maintenance, assembly, container transportation), workshop workpiece transportation, lathe transportation, steel plant (billet, steel plate, coil, steel) pipeline, section steel structure), building (bridge, simple building, concrete column), petroleum industry (oil pump, sucker rod and parts), energy (polycrystalline). Silicon, generator, windmill, chemical industry (electrolyzer, distiller, etc.), railway (railway maintenance, railway welding, train tractor).
The aluminum coil turning transfer cart can run on vertical, L, S and arc guideways.
The aluminum coil turning transfer cart can be used in many situations, such as explosive, high temperature, ferry, etc.
DC motor, stable starting, small starting moment, small impact of reducer, low voltage, long service life…
The aluminum coil turning transfer cart is powered by batteries, which only needs to be fully charged and can run freely without a limited distance.
The aluminum coil turning transfer cart can be customized according to your actual needs.
Aluminum coil turning transfer cart are suitable for various occasions, such as industry, (steel mills, steel structures, steel tubes, billets, ladles and coils transfer steel products from one place to another; paper coil mills: transfer paper coil coating workshop: transfer work pieces to the spraying room sandblasting room); other industries: shipbuilding, quarries, warehouses and multi-workshop workshops.

This series of motor tractor could be powered by battery,busbar,rail,cable drum,trailing cable and many other ways,you can choose different power supply ways according to your needs.The motor tractors are used to tow the motorless transfer trailer or transport steel coils and pipes for metal industry. This motor tractor are designed  to be an extremely cost effective, safe and flexible load moving alternative.
The coil heavy load transfer cart is sometimes called a heavy transporter, headless transporter or self-propelled modular transporter.

PERFECT heavy die transfer trailers are operating in many shipping lines, stevedores, concrete manufacturers, foundries, steel mills, etc. We have supplied Hybrid Transfer Cart in the world for moving molds inside and outside the plant by electric traction and driving long distances.And also Heavy Load Transfer Carts are mainly used to solve manoeuvrability problems in tight spaces. Due to all possible steering programs, on either one or different axles, you can achieve tight turning radious. The propulsion can be either electric for in-plant load Carts or batteries for long distances.
